Pneumatic products air dryer is an 8.5 m³/min high-temperature refrigerated air dryer designed for compressed air systems with high inlet temperatures. It can handle inlet air temperatures of up to 80°C, while effectively removing moisture from compressed air. Therefore, it is a practical choice for medium-flow applications in demanding working environments.
Air Dryer Specifications
| Model | BRC085F | Capacity | 8.5 Nm3/min |
| Voltage | 220V/50Hz | Power | 1.8kw |
| Inlet/Outlet Connection | G2 | Weight | 220kg |
| Dimensions | 1250*700*1150 mm | Intake temperatures | <80℃ |
| Working pressure | 0.6-1.0Mpa | Pressure dew point | 2-10℃ |
Product Features
High Temperature
This model is specially designed for high-temperature compressed air conditions. With an inlet temperature of up to 80°C, it can work reliably where standard refrigerated dryers may not be suitable. In addition, it helps reduce moisture and protect downstream pneumatic equipment.
Medium Flow
Our Factory
We are a Chinese factory with over 25 years of experience in the compressed air field. We produce refrigerated air dryers, desiccant air dryers, compressed air filters, and other air treatment equipment. Meanwhile, our products have been exported to Indonesia, Vietnam, Malaysia, Portugal, and other countries.
Contact Us
Pneumatic products air dryer provides a reliable solution for medium-flow compressed air systems operating under high-temperature conditions. Overall, its ability to handle up to 80°C inlet air makes it suitable for more demanding applications. With over 25 years of factory experience, we can provide reliable products and professional support.
If you are interested in our products, please contact us for a quotation. We will offer you the most competitive price and the most thoughtful service.
