Dry air dryer is a high-temperature refrigerated air dryer designed for medium-flow compressed air systems. With a rated flow of 8.5 m³/min, it fits many medium-sized factories and production lines. More importantly, it can handle an inlet air temperature of up to 80°C, making it a good choice for applications where normal refrigerated dryers may not work well.
Air Dryer Specifications
| Model | BRC085F | Capacity | 8.5 Nm3/min |
| Voltage | 220V/50Hz | Power | 1.8kw |
| Inlet/Outlet Connection | G2 | Weight | 220kg |
| Dimensions | 1250*700*1150 mm | Intake temperatures | <80℃ |
| Working pressure | 0.6-1.0Mpa | Pressure dew point | 2-10℃ |
Product Features
High-Temperature Design
First, the dryer can handle compressed air with an inlet temperature of up to 80°C. This makes it suitable for hot-air applications and demanding factory environments. At the same time, its medium flow capacity makes it easy to match with many medium-sized air compressors.
Stable Refrigeration
Factory Support
Finally, this 8.5 m³/min model reflects our focus on practical and reliable air treatment equipment. We control the key components and test each dryer before shipment. With more than 25 years of manufacturing experience, we also support different voltage, refrigerant, and configuration requirements for overseas customers.
v
Recommend Models
Contact Us
Dry air dryer with high-temperature capability, stable refrigeration control, and automatic drainage can provide reliable compressed air treatment for medium-sized production systems. We continue to improve our products and production capacity to serve more customers in different markets.
