Compressor dryer working plays an important role in keeping compressed air clean and dry. When compressed air leaves the compressor, it often contains a large amount of water vapor. Our 8.5 m³/min plate heat exchanger refrigerated air dryer cools the air and removes the condensed water before it enters the production system. In this way, it helps reduce moisture problems and keeps the air system running smoothly.
Air Dryer Specifications
| Model | BL-60PHE | Intake temperatures | ＜50℃ |
| Capacity | 8.5 Nm3/min | Inlet pressure | 6-16bar |
| Voltage | 220V/50Hz | Pressure dew point | 2-8℃ |
| Power | 1.82KW | Weight | 88kg |
| Inlet/Outlet Connection | G1-1/2" | Dimensions | 650*620*910mm |
Product Features
Stable Drying
During operation, the dryer lowers the temperature of compressed air and separates moisture through condensation. The efficient plate heat exchanger supports fast heat transfer and helps maintain a stable drying process. Therefore, the system can provide reliable air treatment during long working hours.
Medium Capacity
Factory Applications
A wide range of businesses can use this dryer for daily compressed air treatment. It suits metalworking, automotive parts, machinery manufacturing, plastic processing, packaging, electronics, and general industrial workshops. In addition, it works well as part of a complete system with air compressors, storage tanks, and precision filters.
Contact Us
Compressor dryer working shows why proper air treatment matters after compression. By combining effective moisture removal, medium-flow capacity, and efficient plate heat exchange, this 8.5 m³/min refrigerated air dryer provides a practical solution for factories that need stable compressed air.
