Air Compressor For Car Painting
Air Compressor For Car Painting - Image 2
Air Compressor For Car Painting - Image 3
Air Compressor For Car Painting - Image 4

Air Compressor For Car Painting

Model No.PS75+
TypeScrew
Power sourceAC POWER
Lubrication styleOil
MOQ1 Unit
OEM or ODM serviceAvailable

Category: Tags: , , , ,

Oil-cooled variable frequency air compressors achieve an optimal balance of energy efficiency, performance, reliability, and cost through precise flow control and efficient cooling design. Consequently, they are the preferred solution for modern enterprises dedicated to highly efficient and sustainable operations.

Product Specifications

Model No.PS75+Power100HP/75KW
Voltage380V/50HZPressure range0.7-0.8Mpa
Warranty1 yearAir Flow13.4 m³/min
Weight1150KgNoised≤69dB
Dimension1840*1212*1780mmCooling MethodOil-Cooled

Common usage scenarios

Power saving

Mains frequency models always operate at full speed all the time. Even when air demand is low, they still keep running at full capacity, so redundant air gets discharged, which inevitably causes power waste.
As for variable frequency ones, they adjust speed intelligently: they speed up to meet higher air consumption and slow down when less air is required, thus consuming barely any electricity in idle status.
In practical application, they can save 20% to 40% of electricity. Furthermore, the more drastically the air usage fluctuates, the more prominent the power-saving effect will be.

More stable air pressure

Mains frequency type leads to obvious pressure fluctuation with a large pressure difference between high and low values.
In contrast, variable frequency type delivers constant and precise air supply, keeping the pressure difference within 0.1 bar. This ensures far more stable air supply for downstream equipment.

Activate soft

Mains frequency models adopt star-delta starting, which generates huge instantaneous starting current. This will cause impact on the power grid and easily result in equipment tripping.
By comparison, variable frequency units realize soft start, accelerating steadily from zero speed with low starting current, bringing no burden to power lines and transformers.

Recommend Models

Contact Us

Air Compressor For Car Painting is the most cost-effective choice for the vast majority of conventional industrial applications.If you need this product or any similar ones, please contact us for the best quote. We also provide one-stop services for air energy, solutions, and accessories. Please feel free to contact us for any cooperation inquiries or further assistance.
