Oil-cooled variable frequency air compressors achieve an optimal balance of energy efficiency, performance, reliability, and cost through precise flow control and efficient cooling design. Consequently, they are the preferred solution for modern enterprises dedicated to highly efficient and sustainable operations.
Product Specifications
| Model No. | SFC55+ | Power | 75HP/55KW |
| Voltage | 380V/50HZ | Pressure range | 0.7-0.8Mpa |
| Warranty | 1 year | Air Flow | 11.3 m³/min |
| Weight | 1320Kg | Noised | ≤72dB |
| Dimension | 1840*1212*1780mm | Cooling Method | Oil-Cooled |
Maintenance
Quarterly maintenance
Replace the oil filter. Inspect the oil separator and piping for oil contamination and aging. Verify the safety valve and minimum pressure valve to ensure stable pressure. Tighten all electrical wiring terminals to prevent poor contact and damage.
Annual major maintenance
Replace three major consumables: air filter, oil filter, and oil separator element.
Replace the air compressor-specific lubricating oil and clean the oil passages.
Check the main unit rotor and bearing operating noise and clearance.
Deep clean the cooler (water washing/chemical cleaning).
Inspect the motor bearings and add grease.
Comprehensively test the sensors, controller, and frequency converter module.
Replacement cycle of wear parts
Air filter: 3–6 months (shorter in dusty environments)
Oil filter: 3 months
Oil separator element: 6–12 months
Screw lubricant: 4000 hours / 1 year
Solenoid valve, drain: 1–2 years, replace as needed
