The 200 cfm air dryer is designed to provide clean, dry, and reliable compressed air for industrial applications. Built with a high-efficiency refrigeration system, this 6.5m³/min refrigerated air dryer removes moisture effectively and helps protect downstream equipment from corrosion and water damage. Moreover, it delivers stable performance under normal operating conditions while keeping operating costs low. As a result, it is an ideal choice for manufacturing plants, workshops, and compressed air systems that require dependable air quality.
Air Dryer Specifications
| Model | BRA065F | Capacity | 6.5Nm3/min |
| Voltage | 220V | Power | 11.3 kw |
| Inlet/Outlet Connection | G1(1/2) | Weight | 73kg |
| Dimensions | 900*550*880mm | Intake temperatures | <45℃ |
| Working pressure | 0.6-1.0Mpa | Pressure dew point | 2-10℃ |
Product Features
Stable Dew Point
With an optimized cooling system, the dryer maintains a pressure dew point of around 2–10°C under standard operating conditions. Therefore, moisture is removed efficiently before it reaches downstream equipment. Consistent dry air helps improve product quality, reduce system failures, and extend the service life of pneumatic components.
Energy Efficient
Long Service Life
Featuring durable components and a reliable structure, this dryer requires less frequent maintenance and offers a longer service interval. Moreover, stable operation reduces wear on key parts and minimizes unexpected downtime. This helps lower maintenance costs and ensures continuous production.
Recommend Models
Contact Us
The 200 cfm air dryer combines stable dew point performance, economical energy consumption, and a long maintenance cycle in one reliable solution. By delivering clean and dry compressed air, it helps improve production efficiency, protect valuable equipment, and reduce operating expenses.
If you are interested in our products, please contact us for a quotation. We will offer you the most competitive prices and the most attentive service.
