Custom air filters like our 10.0 Nm³/min antibacterial stainless steel filter are designed for compressed air systems that need higher flow and clean air at the same time. It removes dust, oil mist, moisture, and bacteria in one unit, which helps simplify system design and reduce extra equipment. In addition, the compact and practical structure makes installation and daily maintenance easier for users. Moreover, the filter suits a wide range of industries where air quality and stable operation are both important.
Air Dryer Specifications
| Product name | Bacterial-sterilizing stainless steel filter | Filter type | Sterilization Air Filters |
| Filter element size | 15 inches | Working flow | 10.0 Nm³/min |
| Working pressure | 2.5Mpa | Material | Stainless Steel |
| Certificate | ISO9001 | Warranty | 1 Year |
Product Features
Strong Antibacterial Filtration Ability
This filter supports filtration grades from 0.01–0.1 μm, so it can block very small particles and most bacteria in the air. The overall filtration efficiency can reach up to 99.9%, which improves air cleanliness and process safety. In addition, the antibacterial filter media reduces bacterial buildup inside the housing, so performance stays consistent over time.
Long-Lasting Stainless Steel Structure
The housing is made of 304 stainless steel, while 316 stainless steel is available for higher corrosion resistance. Because of this, the filter works well in humid or demanding environments. It also supports working pressures up to 1.0 MPa and inlet temperatures up to 80°C, which makes it suitable for many industrial conditions.
Large Capacity with Low Energy Loss
Designed for a rated flow of 10.0 Nm³/min, the internal airflow path stays smooth and balanced. As a result, the pressure drop remains low, typically around 0.02–0.03 MPa. This helps reduce energy consumption and keeps operating costs under control.
Contact Us
Custom air filters such as this 10.0 Nm³/min antibacterial stainless steel filter deliver stable quality and reliable performance. This antibacterial stainless steel filter is of good quality; if you need this product or similar related products, please contact us for a quotation. We will recommend suitable solutions and provide you with professional and satisfactory service.
